Modsort Mid-Rate Sortation Conveyor System

This Modsort Sortation Conveyor system project was custom designed by SJF for a customer. The Modsort system is a mid-rate sorter conveyor capable of sorting up to 30 cartons/minute. 24V technology allows easy modification, addition, or moving of divert locations. The all-belt design allows efficient sortation of polybags, boxes, and totes. This makes it an ideal fit for many growing e-commerce facilities.

To see more, check out our “What is Sortation Conveyor” page.

If you’d like some information on a specialized sortation systems, contact our Solutions Specialists at (320) 485-4974, Sam Sterner at (320) 485-4970 or email support@sjf.com. #sortationconveyor #warehouseconveyor #automation

Guest Post: Conveyor Roller Types and Their Benefits

Conveyor Systems

Today’s post is courtesy of Emma Smith

The conveyor systems’ most vital part is the type of conveyor roller which is being used. Different types of packaging and products require different rollers. In the manufacturing of the conveyor rollers, various types of materials are used such as metallic, rubber, or plastic, depending on their usage in regular business operations.

Conveyor rollers or conveyor belts use rollers as uniformly spaced rotating cylinders-in order to allow items to move through their surface. The objects can be pushed manually, by gravity or by electricity. The transported material needs a robust riding surface that is accompanied by at least three rollers.

Conveyor rollers are suitable for accumulation or gathering applications as rollers can reduce the product inertia at a high speed making them useful conveyors and alongside a high-speed sorting machine. The application of conveyor rollers is crucial along with the type of environment and facility that needs to be considered.

Application of conveyor rollers

A roller conveyor system can be customized to operate with a range of ancillary equipment including twists, gates, and turntables. Regardless of the nature of the goods being transported, roller conveyors are commonly used in areas such as warehouses or manufacturing facilities.

The use of a roller conveyor can add flexibility to the type of transfers, converters, and stops that can be used as part of a conveyor system or automation system. You can use either mild steel, galvanized, acrylic, or stainless-steel roller conveyors.

Roller conveyor systems are commonly used in various industries, especially logistics and manufacturing because of their adaptability and use. There are many industries which use roller conveyors. Some of them are:

  • Food handling
  • Packaging
  • Logistics
  • Mail delivery services
  • Baggage handling
  • Steelmaking
  • Manufacturing and design

Specific roller conveyor types include:

Coated (covered) conveyor roller

These are advanced rollers, which are covered with plastic or rubber. This roller is widely used in the paper manufacturing and metal rolling and printing industry. The coated form of rollers integrates grinding through the coating material with a significantly high degree of grip for better performance.

Gravity conveyor roller

Gravity conveyor roller is a frame, which sustains free rotating rollers and uses gravity to skid the material down. Medium to lightweight products can be easily carried with this conveyor and it is an economical solution as it does not require a motor. It can be made with plastic aluminum and steel.

This type of conveyor roller blends advanced structural features with off-the-shelf design requirements. The conveyor rollers are, therefore, best used when handling odd-shaped cartons, bags, and boxes of low quality.

Motorized conveyor roller

Motorized rollers can integrate directly into the conveyor frames. They are used for automated materials handling systems. Motorized roller conveyors are an excellent choice where the primary considerations are energy consumption, quiet operation, and ease of maintenance. They are also known as MDR (motorized roller conveyors or “motor-driven roller conveyors”).

The rollers in this class come packed with control drums to control the speed and flow of the under-transportation products. Material sorting and analysis can be easily automated throughout the entire transport cycle through the motorized zones. Such rollers are, therefore, best used in advanced automated production lines.

Motorized drums are built as compact integrated belt conveyor-drive drum. There is no exposed gearbox, electric motor, or chain drive and they are sealed to IP65, which protects them from dust and water intake.

Free spinning conveyor roller

These rollers are bearing-laden, created with an integrated free turn capability. The rollers are useful for creating conveyor belt support systems as well as for applications in areas that require highly flexible rotational performance and low friction.

Free spinning rollers are also used to support the belt underneath the conveyors. These rollers have bearings inserted into the ends that allow free turning of the roller.

Select the best conveyor roller system

The conveyor roller system is versatile and customizable. It can be easily dismantled and moved easily. The main use of the roller conveyor system is to transport goods from one place to its destination. They can reduce the need for a large workforce, save time, and energy.

Innovation in Automation Alive & Well in Minnesota

spiral curve, conveyor spiral, automation, SJF material handling

The SJF automation team continues to spearhead going projects for growing businesses here in Minnesota. Final testing and work was completed on this pre-owned powered spiral conveyor this past week. An impressive piece of equipment, this spiral is just one of the many components associated with several ongoing automation projects that Frank  Sterner’s team of  Matt Johnson, Dave Kiefer, Brian Springer currently have in the works.

According to project manager Frank Sterner, the powered spiral shown below is just one of several  automation components scheduled to be installed for a growing order fulfillment operation SJF is working with right here in Minnesota.

Powered Spiral Conveyor (3 of 6) Powered Spiral Conveyor (4 of 6) Powered Spiral Conveyor (6 of 6)

Featured Client: United Mailing Services

Powered Conveyor
Powered Conveyor

More than twenty years ago, United Mailing Services, Inc. (UMS) got its start in the owner’s basement. That was in 1989 when mail was sorted by hand. Since then UMS and the United States Postal Service have gone through many changes. By 1997 UMS expanded throughout the entire state of Wisconsin. Being a privately owned business which does work share with the United States Postal Service, UMS has become a leader in the automation industry.

UMS serves hundreds of clients, ranging from small local businesses to Fortune 500 companies throughout Wisconsin. In 2011 they expanded their business once again by offering high-speed digital color print to better serve the needs of their customers.

Read more

SJF’s New Sweep Sorter

Overall View of Sweep Sorter

SJF engineer Matt Johnson & systems integrator Frank Sterner team up with SJF’s fabrication pros to create, fabricate and program a first-of-its-kind sweep sorter.

This is a very specialized piece of equipment capable of sorting hard to sort packages and bagged product (aka Halloween & other Costumes). This was specifically designed for a Minnesota client to quickly process and fill incoming sales orders quickly while minimizing errors.

This system will allow the company to vastly increase the number of orders they can process as well accommodate future growth and product demand.



Read more
